EDIT: Updated to .NET 8 and improved content.

In my previous post I left out ArraySegment<T>. This is a value-type that implements a way to reference slices of arrays.

ArraySegment<T> is older and somewhat similar to Span<T>.

ArraySegment<T> has a lot less usage limitations than Span<T>. Span<T> cannot be used as a generics type and can only be used as a field type inside a ref struct. With any other struct, or class, you’ll have to use a Memory<T> field type. To enumerate a Memory<T>, you have to call its Span property, which creates a new instance of Span<T>. This may be a big performance hit if, for example, the type containing this field has a method that accesses just one item. It takes time to create the Span<T> instance to then simply access a memory location.

Span<T> supports arrays and other types of contiguous memory allocations. ArraySegment<T> only supports arrays.

Span<T> and Memory<T> don’t implement IEnumerable<T> so the LINQ operations defined in System.Linq cannot be used. You’ll have to use NetFabric.Hyperlinq or SpanLinq libraries. ArraySegment<T> implements IEnumerable<T> so it can be used with any LINQ implementation.

So, how do these fairs in terms of performance?

Let’s use BenchmarkDotNet to run the following benchmarks:

using System;
using System.Linq;
using BenchmarkDotNet.Attributes;

namespace ArrayIteration;

public class ArraySegmentBenchmarks
{
    protected ArraySegment<int> arraySegment;

    [Params(100)]
    public int Offset { get; set; }

    [Params(10, 1_000)]
    public int Count { get; set; }

    [Params(2_000)]
    public int Length { get; set; }

    [GlobalSetup]
    public void GlobalSetup()
    {
        var array = Enumerable.Range(0, Length).ToArray();
        arraySegment = new ArraySegment<int>(array, Offset, Count);
    }

    [Benchmark(Baseline = true)]
    public int For()
    {
        var sum = 0;
        for (var index = 0; index < arraySegment.Count; index++)
            sum += arraySegment[index];
        return sum;
    }

    [Benchmark]
    public int ForEach()
    {
        var sum = 0;
        foreach (var item in arraySegment)
            sum += item;
        return sum;
    }

    [Benchmark]
    public int Linq()
        => arraySegment
            .Sum();

    [Benchmark]
    public int Array_For()
    {
        var array = arraySegment.Array!;
        var start = arraySegment.Offset;
        var end = start + arraySegment.Count;
        var sum = 0;
        for (var index = start; index < end; index++)
            sum += array[index];
        return sum;
    }

    [Benchmark]
    public int AsSpan_ForEach()
    {
        var sum = 0;
        foreach (var item in arraySegment.AsSpan())
            sum += item;
        return sum;
    }

    [Benchmark]
    public int Array_Linq()
        => arraySegment.Array!
            .Skip(Offset)
            .Take(Count)
            .Sum();
}

These benchmarks use an array of 2.000 integers. It creates a ArraySegment<int> with an Offset of 100 and two different Count values, 10 and 1.000 items.

The For() bechmarks uses a for loop to iterate the ArraySegment<T>. It uses its indexer to get the item.

The ForEach() benchmark uses a foreach loop to iterate the ArraySegment<T>.

The Linq() benchmark uses the Sum() provided by the System.Linq namespace.

The Array_For() benchmark uses a for loop on the inner array of ArraySegment<T>. The inner array is available through the Array property, and the segment properties are available through the Offset and Count properties.

The Span_ForEach() benchmark uses AsSpan() and a foreach loop to iterate the inner array of ArraySegment<T>. As you can see in its source, AsSpan() uses the Array, Offset, and Count properties to create a Span<T> equivalent to the ArraySegment<T>.

The Array_Linq() benchmark uses on the inner array the Skip(), Take(), and Count() operations provided by the System.Linq namespace.

Here are the bechmarking results using a configuration to test on .NET 6, .NET 7 and .NET 8 (all “modern” .NET versions):

ForEach() is around 1.3x slower than For() for the shorter collection. Unlike arrays and Span<T>, the C# compiler doesn’t treat ArraySegment<T> as a special case. foreach does not use the indexer. It allocates an instance of an enumerator and uses it. Although the enumerator is a value-type, it’s still slower than using the indexer.

Both the indexer and the Current property of the enumerator check bounds twice. One explicitly in the code and another implicitly when indexing the array. The indexer does it in a more efficient way with only one comparison but Current does it with two comparisons.

Linq() is around 10x slower than For(), but 3x to 5x slower when on .NET 8. Adding to the double bounds checking in the Current property, it boxes the enumerator, making it a reference-type.

NOTE: Check my other article “Performance of value-type vs reference-type enumerators” to understand why having a value-type enumerator is an advantage.

The Array_For() and AsSpan_ForEach() have similar performance. These are 1.6x to 2x faster than For(). These are equivalent and faster because the array is copied to a local variable so the JIT compiler can remove bounds checking.

NOTE: Check my other article “Array iteration performance in C#” to understand how the JIT compiler can remove bounds checking.

The Array_Linq() is 8x to 20x slower than For() because more enumerators are used. Notice that 96 bytes are allocated against the 72 bytes allocated by the Linq() benchmark. Skip() and Take() are optimized to create only one enumerator when used together but still adds this extra enumerator.

Conclusions

Using the indexer or the enumerator of a ArraySegment<T> is slow. Given that it’s possible to access its inner array, it’s just like having the array and the slice bounds in a value type. Using it this way, allows to work around a the Memory<T> indexing one element performance limitation.

Avoid the use of LINQ with ArraySegment<T> when possible.
